Unraveling the Power of Rotary Bending Straightening: Precision Redefined
Introduction:
In the world of metalworking, precision and accuracy are paramount. Rotary bending straightening machines have emerged as indispensable tools for achieving exceptional levels of precision, straightness, and flatness in metal components. In this blog, we will delve into the main functions and product features of rotary bending straightening machines, guiding you through the intricacies of this transformative technology. If you're looking to elevate your metalworking game, read on, and discover how rotary bending straightening can be a game-changer for your projects.
Main Functions:
1.Bending and Straightening Precision: Rotary bending straightening machines are designed to restore the straightness of metal bars, tubes, and profiles. By carefully manipulating the material with precision rollers and controlled pressure, they can correct distortions, such as bow, camber, or coil, ensuring the end product meets strict quality standards.
2.Flatness Enhancement: These machines are masters in creating flat surfaces. They can handle both concave and convex shapes, gradually bending the material into alignment. This is crucial for industries where flatness is non-negotiable, such as construction, automotive, and aerospace.
3.Versatility: Rotary bending straightening machines are not limited to one type of material. They can efficiently handle various metals like steel, aluminum, copper, and more, making them versatile assets for metalworking operations.
Product Features:
1.Precision Rollers: The heart of rotary bending straightening machines lies in their precision rollers. These rollers are engineered to provide consistent, controlled force, ensuring the material is straightened accurately.
2.User-Friendly Controls: Modern machines come equipped with user-friendly interfaces that allow operators to set parameters easily, monitor progress, and make adjustments as needed. This ensures that the straightening process is both efficient and customizable to specific requirements.
3.Robust Construction: These machines are built to withstand the rigors of heavy-duty industrial applications. High-quality materials and robust construction ensure durability and longevity.
4.Safety Measures: Safety is paramount in any industrial setting. Rotary bending straightening machines are equipped with safety features like emergency stop buttons and protective guards to safeguard both operators and the equipment itself.
5.Quality Assurance: Many machines are equipped with advanced measurement and inspection systems to ensure the straightened product meets the highest quality standards.
Product parameters
Model | Модель | MC-40 | MC-60 | MC-80 | MC-40 | MC-100 | MC-150 |
Main power supply | Основной источник питания | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ | AC 380V 50HZ |
Control power supply | Блок питания управления | AC 220V 50HZ | AC 220V 50HZ | AC 220V 50HZ | AC 220V 50HZ | AC 220V 50HZ | AC 220V 50HZ |
Control power supply | Мощность системы управления | DC24V | DC24V | DC24V | DC24V | DC24V | DC24V |
Rectification length (standard configuration-6m) | Длина выпрямления (стандартная конфигурация — 6 м) | ≧1m | ≧2m | ≧2m | ≧1m | ≧2m | ≧2.5m |
Processing range | Диапазон обработки | ∮8-40 | ∮18-60 | ∮20-80 | ∮8-40 | ∮20-100 | ∮70-150 |
Straightening speed | Скорость выпрямления | 1-25m/min | 1-25m/min | 1-18m/min | 1-25m/min | 1-18m/min | 1-10m/min |
Straightening roller speed | Скорость выпрямляющего ролика | 1-140rpm | 1-140rpm | 1-63rpm | 1-140rpm | 1-63rpm | 1-63rpm |
Surface roughness (for hot-rolled material) | Шероховатость поверхности (для горячекатаного материала) | Ra1.6-0.8 | Ra1.6-0.8 | Ra1.6-0.8 | Ra1.6-0.8 | Ra1.6-0.8 | Ra1.6-0.8 |
Diameter tolerance (excluding head and tail material 100 mm) | Допуск на диаметр (исключая материал головки и хвоста 100 мм) | ≦h8 | ≦h8 | ≦h8 | ≦h8 | ≦h8 | ≦h8 |
Linearity (raw material) | Линейность (сырье) | ≦2‰ | ≦2‰ | ≦2‰ | ≦2‰ | ≦2‰ | ≦2‰ |
Linearity (finished product) | Линейность (готовый продукт) | ≦0.5‰ | ≦0.5‰ | ≦0.5‰ | ≦0.5‰ | ≦0.5‰ | ≦0.5‰ |
Installed capacity | Установленная мощность | 48KW | 63kW | 115KW | 48KW | 155KW | 187kW |
Dimensions (LxWxH in metres) | Размеры (ДxШxВ в метрах) | 14*4*2 | 14*4*2.5 | 15*4.5*3 | 14*4*2 | 15*4.5*3.5 | 16*4.5*4 |
Weight | Масса | 4T | 7T | 18T | 4T | 26T | 35T |
Taking the Next Step:
If you're interested in harnessing the power of rotary bending straightening for your metalworking projects, we're here to help. Our experts are ready to answer any questions you may have and guide you through the selection process. Whether you're looking to improve the straightness of your materials or enhance flatness, our machines are designed to meet your needs.
To get started, simply send us your inquiry by clicking [here]. We're excited to be a part of your journey to precision and excellence in metalworking.
In conclusion, rotary bending straightening machines offer a world of precision, versatility, and quality in the realm of metalworking. They are the unsung heroes behind perfectly straight, flat, and flawless metal components. So, if you're ready to take your metalworking to the next level, don't hesitate to get in touch. Your quest for precision starts here.
